Processing & Customization

Custom profiles

Unlock limitless structural possibilities with our Custom Steel Profiles, designed to go beyond the constraints of standard hot-rolled sizes. We specialize in manufacturing bespoke T-Bars, H-Beams, Channels, and Angle Bars using advanced Laser Fusing technology, which achieves sharp, clean corners (R≤0.5mm) ideal for high-end architectural curtain walls and precision machinery. Whether you require unequal legs, non-standard web thicknesses, or specific lengths in Stainless Steel (304/316L), Duplex 2205, or Carbon Steel, we fabricate strictly according to your CAD drawings. This ensures a perfect structural fit and superior aesthetic finish for projects where standard off-the-shelf profiles simply won't suffice

Specification Category: Technical Details & Customization Capabilities
Product Name: Custom Stainless Steel Profiles / Special Structural Sections
Profile Types: T-Bar / T-Section (Structural & Decorative) H-Beam / I-Beam (Custom dimensions not available in hot rolled) C-Channel / U-Channel / Z-Profile Angle Bar (Unequal legs, non-standard thickness) Free-Form Sections (Based on CAD drawings)
Fabrication Technology: 1. Laser Fusing (Laser Welding): Sharp corners (R≤0.5mm), full penetration, for high-end facades. 2. Hot Rolling: For large volume, standard rounded corners. 3. Cold Drawing: For high precision, smooth surface small profiles. 4. Press Brake Bending: For thin-wall open profiles from sheet.
Material Options: Stainless Steel: 304/304L, 316/316L, 316Ti, 321 Duplex Steel: 2205 (S31803), 2507 (S32750) Carbon Steel: S355, Q345B, A572 Gr.50 Special Alloy: 904L, Inconel (Upon Request)
Size Capability: Height (H): 20mm – 1000mm Width (B): 20mm – 500mm Web Thickness (t1): 3mm – 60mm Flange Thickness (t2): 3mm – 60mm
