Copper Bar & Profile
Oxygen-free copper rod
Oxygen-Free Copper Rod is solid bar stock made from Oxygen-Free Copper (OFC), typically corresponding to C10200 (≥99.95% Cu) or the purer C10100 (≥99.99% Cu). The very low oxygen content provides extremely high electrical and thermal conductivity (≥99.8% IACS) and, crucially, grants complete immunity to hydrogen embrittlement. This makes it superior to ETP copper for high-temperature joining. OFC rod is used in applications demanding the highest standards of performance and purity, including high-quality electrical conductors, vacuum components, high-efficiency heat sinks, and magnet wire where consistent conductivity and reliable brazing are essential.
- Product Name
- Oxygen-Free Copper Rod (OFC Rod)
- Material Grades
- C10100 (OFE - Oxygen-Free Electronic, Min. 99.99% Cu), C10200 (OF - Oxygen-Free, Min. 99.95% Cu)
- Standard
- ASTM B49, ASTM B187, DIN 2.0040, JIS H2123, EN 13601 (CW008A/CW009A)
- Oxygen Content
- Max 0.0005% (5 ppm) for C10100
- Purity (Cu + Ag)
- Min 99.99% (C10100) or Min 99.95% (C10200)
- Electrical Conductivity
- Min 101% IACS (Typical: 101.5% - 102% IACS)
